Destaco 205-UB Horizontal Hold-Down Toggle Locking Clamp

Product Details

SKU

205-UB

Vendor
Inventory
$25.97

Out of stock

Shipping Calculated at checkout

Description

205 -UB Supplied with neoprene spindle assembly

• U-bar clamp arm
Model no.: 205-UB
Maxmum Holding Capacity (N): 270
Maximum Holding Capacity (lbsf): 60
Clamp Arm Length (mm): 18.5
Clamp Arm Length (in): 0.730
Height Under Clamp Arm (mm): 11.2
Height Under Clamp Arm (in): 0.440
Clamp Bar Opening (+10°) (degrees): 90
Handle Opening (+10°): 80
Standard Material: Steel
Toggle Lock Plus: No
Accomodates Workpiece Variation: No
Base Mounting Style: Straight
Clamp Arm Style: U-Bar
Handle: Horizonal
Service Environment: Normal
Duty Cycle: 2
Product Type: Standard
Holding force: 250: N
Angle: 90°
Standard equipment: 205208-M
Weight: 0.03 kg / 0.07 lb

Application: Welding:
Poor/Low, Assembly: Excellent/High, Checking Fixtures: Excellent/High, Machining: Poor/Low, Wood-Working: Excellent/High, Closures: Excellent/High, Food Processing: Fair/Medium

Specifications

Product Type:
Clamp
