Description
Features and Specifications: 807-S Light-Duty Pneumatic Hold-Down Clamp
- Maximum Holding Capacity (N): 2,220
- Maximum Holding Capacity (lbsf): 500
- Clamp Arm Length (mm): 80.0
- Clamp Arm Length (in): 3.130
- Height Under Clamp Arm (mm): 35.0
- Height Under Clamp Arm (in): 1.380
- Cylinder Bore (mm): 32
- Cylinder Bore (in): 1.26
- Port Size: 1/8 NPT
- Clamp Arm Style: Solid
- Application – Welding: Fair/Medium
- Application – Assembly: Excellent/High
- Duty Cycle: Fair/Medium
- Operating Temperature: -10° to 90°C (-14° to 194° F)
- Product Type: Pneumatic Toggle Clamp
- Exerting Force (N): 2412
- Exerting Force (lbf): 540
- Air Consumption (dm²): 0.42
- Air Consumption (ft²): 0.015
- Replacement Seal Kit: 802450-32-1-00
- Weight: 0.75kg [1.66lb]
- Bar Opens: 92°
Additional Notes:
- Sensor ready for round or T-slot sensors.
- Built-in flow restriction eliminates need for external flow controls
- Pneumatic version of 207 manual toggle clamp
- Supplied with bolt retainer
- Replacement Clamp Assembly: 807-S-LC
- Pneumatic version of models 207-U and 207-S manual clamp
- Pneumatic cylinder features built in flow control for smooth operation and magnetic ring piston for position sensing
- Accommodates either T-slot (8EA-109-1) or round (810169) sensors
Specifications
Product Type:
